10 SERIES - Options & Specs (See 10 Series)


SWIVEL CROSS SECTION. 1/2” KING PIN IS STANDARD. OPTIONAL 3/4” KING PIN AVAILABLE FOR AN ADDITIONAL CHARGE.

Optional Larger Top Plate.
For an additional charge of $12.00.
Specs: Plate is 5” x 5-1/2” Bolt Holes: 4-1/8”x4-1/2” Add a -A to part number for this option
Add Item to Shopping Cart

OPTIONS:

THREADED STEMS: Threaded stems are for SWIVEL casters only. Rigid casters can be modified by special order only. We stock 3/4"-10x1-1/2" in stock. Call for pricing.

BRAKES: A brake locks the wheel from rolling. They are usually mounted to the swivel. We have 3 types of brakes in stock.

  • Side Locking Brake. This brake is mounted on the side of the caster and simply “pinches” the legs of the caster against the hub of the wheel using a cam type action. Ideal for steel wheels or phenolic wheels. This brake can also be mounted to a rigid caster. Effective. Inexpensive.
  • Top Locking Brake or otherwise known as a “tread lock brake”. This brake is mounted as an intricate part of a swivel caster. A very effective means for braking the wheel. When the wing pedal is activated a “shoe” is pulled against the top of the wheel creating a positive lock. Very Effective. Cost efficient.
  • Total Lock Brake. This brake locks the wheel and the swivel at the same time. Also an intricate part of the swivel caster. Usually a pedal on top of the wheel activates this brake. An extremely effective means for braking the caster from rolling. If you need absolute stopping ability, this is your brake.
  • Swivel Locks: This devise locks a swiveling caster and converts the caster to a fixed position or “rigid” caster. A spring plunger pin locks the swivel in either of 4 positions when activated. Effective and inexpensive.
  • Side Locking Brake: Add -SB to part number. Add $ 7.60 to caster price. Swivel or Rigid.
    Add Item to Shopping Cart
  • Top Locking Brake: Add -TLB to swivel part number. Add $ 10.00 to SWIVEL caster price.
    Add Item to Shopping Cart
  • Total Lock Brake: Add -TTL to SWIVEL part number. Add $ 18.00 to swivel caster price.
    Add Item to Shopping Cart
  • Swivel Lock: Add to SWIVEL part number. Add $ 10.00 to swivel caster price.
    Add Item to Shopping Cart

    STAINLESS STEEL: Call for pricing.
    CHROME PLATING OR NICKEL PLATING: Call for pricing.
    NEW KING-PIN-LESS CASTERS: Please call for pricing.

    OTHER OPTIONS AVAILABLE. Please call with your needs.
